  • Efficiency is built-in with each of the provided models, like drag/drop of fault locations onto modeled lines for quicker end-to-end tests of zone/reach distances.
  • Enter the line parameters and Protection Suite 5.0 builds a model of your actual line.
  • Create various line configurations (single line, parallel line, bus differential, et al) and create faults on those lines.
  • Configure up to 256 timers at selected sampling points and stream transient data directly to the Doble F-6000 instrument for GPS-synchronized end-to-end testing as part of your diagnostic investigations.
  • Parse the event data into discrete, user-defined fault states for powerful sequencing of transient waveforms.
  • Import data from COMTRADE, PL4, or TransWin3 formats to evaluate relay/scheme performance using test quantities derived from actual power system events.
  • Auto-populate test states with data from SS1, SS2, or TransWin3 state simulation files.
  • Model complex characteristics and incorporate GPS-synchronized end-to-end tests in your Protection Suite 5.0 dynamic test plans.
  • Protection Suite 5.0 has graphical protection characteristics formed from in-service settings that model relay functions in their entirety.
  • #POWER SUITE PDF FULL#

    Up to 512 test states can be created, each with assignable sources and full control of timers and sequencing.Prove relay logic and protection schemes by simulating power system conditions with pre-fault/fault/post-fault state sequences.Protection Suite 5.0 provides an expansive pick list of industry-proven steady state test macros plus the Test Plan Builder and wizards for streamlining new test creation.Manipulate the magnitude, angle, or frequency of voltage or current throughout a test to find discrete relay operate points.Equivalent to all legacy ProTesT tests.

    power suite pdf

    #POWER SUITE PDF MANUAL#

    Protection Suite 5.0 provides a robust platform for a variety of test techniques: Manual Control Tests Apply your custom scripting directly to worksheets and formula calculations to enhance the automation and flexibility of your Protection Suite tests. Write Visual Basic modules that perform subroutine functions called during test operations.Worksheet formulas can be constructed to adapt dynamically when exposed to different relays having different settings. Use embedded worksheets to perform formula calculations for virtually every parameter based from the applied settings.Additionally, users can create and customize their own settings templates as desired. Use these new tools for automated setup of test values in Protection Suite 5.0 test plans for ABB Relion, GE/Schneider MICOM, Siemens SIPROTEC or other relays that read/write settings data using the XRIO file format. New pre-built settings templates for relays that use the XRIO format are also available. With Protection Suite 5.0, new settings importers for XRIO file types are provided.Use the settings import tool or custom scripts and have access to relay configurations within Protection Suite. Use settings importers to automate the population of relay settings values into your Protection Suite test plans.F6 instrument calibrations (using the F6080) that generate calibration certificates.Test data and settings management with reporting and security.Customizable solutions for manual data entry and management of documentation.

    #POWER SUITE PDF VERIFICATION#

  • Digital, IEC 61850 testing of IEDs and verification of GSE, GOOSE, R-GOOSE, and 9-2LE sampled values.
  • Transient wave form streaming for advanced harmonics testing.
  • power suite pdf

    #POWER SUITE PDF GENERATOR#

  • Playback of IED-recorded events and ability to create custom waveforms using the embedded wave generator feature.
  • #POWER SUITE PDF SOFTWARE#

  • Sequencing of realistic power system events using COMTRADE samples formatted from system devices or generated by software.
  • Ability to create models of line configurations and perform end-to-end and fault location testing in state simulations.
  • Settings-driven visual protection characteristics and test functions.
  • power suite pdf

    Expansive set of industry-proven, pre-built steady state and dynamic tests.Limitless incorporation of formulas, worksheets and scripting for powerful and fully customized test operations.Applications for testing relays, CT/VT wiring to relays, phasor measurement units, transducers and meters.

    power suite pdf

  • Instrument control and firmware version management.
